Milwaukee® 2974-20 M18™ Pipeline Inspection Reel, 3 to 10 in Pipe, Battery
Milwaukee® 2974-20 M18™ Pipeline Inspection Reel, 3 to 10 in Pipe, Battery
Milwaukee® 2974-20 M18™ Pipeline Inspection Reel, 3 to 10 in Pipe, Battery
Milwaukee® 2974-20 M18™ Pipeline Inspection Reel, 3 to 10 in Pipe, Battery
Milwaukee® 2974-20 M18™ Pipeline Inspection Reel, 3 to 10 in Pipe, Battery
Milwaukee® 2974-20 M18™ Pipeline Inspection Reel, 3 to 10 in Pipe, Battery

Click to enlarge
Milwaukee®
2974-20

Milwaukee® 2974-20 M18™ Pipeline Inspection Reel, 3 to 10 in Pipe, Battery

Milwaukee® 2974-20 M18™ Pipeline Inspection Reel, 3 to 10 in Pipe, Battery

Catalog Number:
Manufacturer: Milwaukee Tool
Brand: Milwaukee®
Item ID: MILW 2974-20
MPN: 2974-20
Min Order Qty: 1

The Milwaukee® 200’ Pipeline Inspection Reel designed for 3”-10” drain lines is powered by the M18™ 500 GB Control Hub and is a part of the M18™ Modular Pipeline Inspection System. The industry’s shortest 34 mm 1080p HD self-leveling camera head provides the ability to digitally zoom up to 4X with optimized light output inside of the pipes.This allows technicians to see more in drain lines than ever before. The sewer line camera inspection system has a telescoping handle and wide wheelbase, making transportation on and off the job easier. The 200’ Pipeline Inspection Reel comes equipped with small and medium camera skids as well as a camera head sleeve to center and protect the camera while inside pipes.

Milwaukee® Pipeline Inspection Reel, Series: M18™, 3 to 10 in, 200 ft Push Rod Length, 34 mm Camera Dia, 18 V, Battery, M18™ Wireless Monitor, Self-Leveling Camera

Sold As: EACH
Springfield

Features

  • 1080p camera resolution providing the industry's clearest image inside of drain lines
  • 12 Mm push cable diameter provides stiffness to push maximum distance
  • Line trace frequency - 33 kHz, 83 kHz
  • Powered by the M18™ 500 gb control hub
  • Extendable handle and wide wheelbase provide maximum stability
  • On board monitor mount for viewing and transportation
  • Line Capacity - 3 in-10 in

Specifications

Cable Diameter
15/32 in
Cable Length
200 ft
Camera Diameter
34 mm
Camera Type
Self-Leveling
Color
Red/Black
Height
21.9 in
Length
19 in
Max. Pipe/Tube Diameter
10 in
Min. Pipe/Tube Diameter
3 in
Monitor Type
M18™ Wireless
Pipe Capacity
3 to 10 in
Power Source
Battery
Push Rod Length
200 ft
Series
M18™
Voltage Rating
18 V
Voltage
18 V
Warranty
5 Years
Width
21.9 in

The Milwaukee® 200’ Pipeline Inspection Reel designed for 3”-10” drain lines is powered by the M18™ 500 GB Control Hub and is a part of the M18™ Modular Pipeline Inspection System. The industry’s shortest 34 mm 1080p HD self-leveling camera head provides the ability to digitally zoom up to 4X with optimized light output inside of the pipes.This allows technicians to see more in drain lines than ever before. The sewer line camera inspection system has a telescoping handle and wide wheelbase, making transportation on and off the job easier. The 200’ Pipeline Inspection Reel comes equipped with small and medium camera skids as well as a camera head sleeve to center and protect the camera while inside pipes.

Milwaukee® Pipeline Inspection Reel, Series: M18™, 3 to 10 in, 200 ft Push Rod Length, 34 mm Camera Dia, 18 V, Battery, M18™ Wireless Monitor, Self-Leveling Camera
