Chicago-Latrobe® 78492 780 Stub Length Spade Drill, 3/8 in Drill - Fraction, 0.375 in Drill - Decimal Inch, 1 in D Cutting, 2 Flutes, Solid Carbide
Chicago-Latrobe® 78492 780 Stub Length Spade Drill, 3/8 in Drill - Fraction, 0.375 in Drill - Decimal Inch, 1 in D Cutting, 2 Flutes, Solid Carbide
Chicago-Latrobe® 78492 780 Stub Length Spade Drill, 3/8 in Drill - Fraction, 0.375 in Drill - Decimal Inch, 1 in D Cutting, 2 Flutes, Solid Carbide

Click to enlarge
CHICAGO-LATROBE
78492

Chicago-Latrobe® 78492 780 Stub Length Spade Drill, 3/8 in Drill - Fraction, 0.375 in Drill - Decimal Inch, 1 in D Cutting, 2 Flutes, Solid Carbide

Chicago-Latrobe® 78492 780 Stub Length Spade Drill, 3/8 in Drill - Fraction, 0.375 in Drill - Decimal Inch, 1 in D Cutting, 2 Flutes, Solid Carbide

Catalog Number:
Manufacturer: Greenfield
Brand: CHICAGO-LATROBE
Item ID: GRFL 78492
MPN: 78492
Min Order Qty: 1

Chicago-Latrobe® Spade Drill, Stub Length, Series: 780, Imperial, 3/8 in Drill - Fraction, 0.375 in Drill - Decimal Inch, 2-1/2 in Overall Length, 1 in Cutting Depth, 2 Flutes, Straight Flute, 1 in Flute Length, 3/8 in Dia x 1-1/2 in L Shank, Straight Shank, 118 deg Point, Radial Point, Right Hand Cutting Direction, Solid Carbide Cutting Edge, Applicable Materials: Hardened Materials, Non-Ferrous Metals and Stainless Steel, Thin Sheet Metal and Shallow Hole Drilling, Solid Carbide, Bright

Sold As: 1/PK
Springfield

Features

  • Stub length for rigid setups

Specifications

Applicable Materials
Hardened Materials, Non-Ferrous Metals and Stainless Steel
Bit Type
Stub Length Drill Bits
Coating/Finish
Bright
Cutting Depth
1 in
Cutting Direction
Right Hand
Cutting Edge Material
Solid Carbide
Diameter (Decimal)
0.375
Diameter (Fractional)
3/8
Diameter (Metric)
9.53
Diameter
3/8 Inch
Drill Construction
Straight Flute
Drill Diameter Measurement System
Imperial
Drill Size - Decimal Inch
0.375 in
Drill Size - Fraction
3/8 in
Drill Style
Spade
Drilling Application
Thin Sheet Metal and Shallow Hole Drilling
Finish
Bright
Flute Length (Decimal)
1
Flute Length (Metric)
25.4
Flute Length
1 in
Flute Type
Straight
Hand Of Spiral
Right
Material
Solid Carbide
Number Of Flutes
2
Overall Length
2-1/2 in
Point Angle
118 deg
Point Type
Radial
Series
780
Shank Length (Decimal)
1.5
Shank Length (Metric)
38.1
Shank Length
1.5 Inch
Shank Size (Decimal)
0.38
Shank Size (Metric)
9.52
Shank Size
3/8 in Dia x 1-1/2 in L
Shank Type
Straight
Type
Stub Length
Unit of Measure
Fractional

Chicago-Latrobe® Spade Drill, Stub Length, Series: 780, Imperial, 3/8 in Drill - Fraction, 0.375 in Drill - Decimal Inch, 2-1/2 in Overall Length, 1 in Cutting Depth, 2 Flutes, Straight Flute, 1 in Flute Length, 3/8 in Dia x 1-1/2 in L Shank, Straight Shank, 118 deg Point, Radial Point, Right Hand Cutting Direction, Solid Carbide Cutting Edge, Applicable Materials: Hardened Materials, Non-Ferrous Metals and Stainless Steel, Thin Sheet Metal and Shallow Hole Drilling, Solid Carbide, Bright
